610 Integral Chisel Plow
- John Deere
- Primary & Seedbed Tillage
Find a location to get your local store information and inventory.
Find Location
Key Features & Specs
- Offers a variety of sizes
- Implement warning lights enable safe transport
- Shovels and attaching hardware
- Sweeps and attaching hardware
- Models up to 12 in (306 mm)
- Working Depth 5 to 7 mph (8-11.3 km/h)
- Working Speed 6 to 14 HP/FT (4.5-10.4 kW)
- Required HP (PTO) fracture/mix
- Residue Management medium/heavy
- Residue Conditions 3pt hitch

- + Expand All
- - Close All
-
Implement warning lights enable safe transport
An implement warning light harness with a turn-signal module for two amber and two red lights are included as standard equipment for safe transport on roads.
The implement warning light harness requires one of the following:
- Category 2, 3-point hitch with or without Quik-Coupler
- Category 3 and 3N, 3-point hitch with or without Quik-Coupler
Horsepower requirements
- The rigid and TruPosition™ standards require engine horsepower of 6 hp per ft to 10 hp per ft.
The Tru-Depth™ standard requires engine horsepower of 6 hp per ft to 14 hp per ft.
-
Offers a variety of sizes and excellent residue flow
610 Chisel Plow in corn
The 610 Chisel Plow is available in a variety of sizes to help match tractor horsepower and work designs.
Model
Width
Type of fold
Standards
Three-bar integral 2.44 m to 6.10 m
(8 ft to 20 ft)Non-fold Rigid TruPosition™ Tru-Depth™ Typical percents of the residue cover that remains from the 610 are listed as follows (the percentages do not take into account variables such as the condition of the residue, speed, and soil type):
Starting residue cover (percent)
Remaining non-fragile* residue cover (percent)
Remaining fragile** residue cover (percent)
with
406-mm
(16-in.) sweepswith
51-mm
x
356-mm
(2-in. x 14-in.) chisel pointwith
102-mm x
368-mm
(4-in. x 14.5-in.) shovelwith
76-mm
x
610-mm
(3-in. x 24-in.) shovelwith
406-mm
(16-in.) sweepswith
51-mm
x
356-mm
(2-in. x 14-in.) chisel pointwith
102-mm
x
368-mm
(4-in. x 14.5-in.) shovelwith
76-mm
x
610-mm
(3-in. x 24-in.) shovel100
80
70
60
60
55
50
45
45
90
72
65
55
55
50
45
40
40
80
65
56
50
50
45
40
35
35
70
55
50
42
42
38
35
30
30
60
50
42
35
35
33
30
27
27
50
40
35
30
30
27
25
22
22
40
32
28
25
25
22
20
18
18
*Non-fragile residue includes crops like corn, sorghum, wheat (more than 45 bu).
**Fragile residue includes crops like soybeans, edible beans, peas, wheat (under 45 bu), sunflower, peanuts, cotton. -
Choice of rigid, TruPosition™, and Tru-Depth™ standards
Rigid standard
The rigid standard:
- Is in base equipment on three-section models
- Is 32 mm x 51 mm x 711 mm (1.25 in. x 2 in. x 28 in.)
- Design is suited for fields having few obstructions
- Will till to 203 mm (8 in.) deep
- Good clearance to handle heavy trash
- 711-mm (28-in.) underframe
- 305-mm (12-in.) spacing
TruPosition standard
The TruPosition standard:
- Is optional on all models
- Cast pivot assembly holds shank firm while working in the soil
- Is 32 mm x 51 mm x 711 mm (1.25 in. x 2 in. x 28 in.)
- Shank is replaceable without disassembly of the standard assembly
- Trip action is suited for fields having rocks or other obstructions
- 550-lb trip 711-mm (28-in.) standard will till to 203 mm (8 in.) deep
- 711-mm (28-in.) underframe
- 305-mm (12-in.) spacing
- Trip height of 254 mm (10 in.) for good clearance
- Slotted lower hole to aid in removing ground-engaging tools
Tru-Depth standard
The Tru-Depth standard:
- Is optional on drawn rigid and select drawn flexible models up to 838 mm (33 ft)
- Is 51 mm x 32 mm x 813 mm (2 in. x 1.25 in. x 32 in.); edge is bent for extra strength
- Designed to work in rocky ground and heavy draft conditions
- Will till to 305 mm (12 in.) deep
- Trip height of 279 mm (11 in.)
- 568-kg (1250-lb) trip force
- Excellent clearance to handle heavy trash
- 813-mm (32-in.) underframe
- 305-mm (12-in.) spacing
-
Strong mainframe withstands demanding field conditions
610 rigid frame
The 610 Chisel Plow features a large 102-mm x 102-mm (4-in. x 4-in.) tubular steel mainframe.
Welded construction adds the inner strength that withstands twisting and pulling through demanding field conditions.
-
Operator's manual storage container comes as standard equipment
Operator's manual storage container
A 102-mm (4-in.) diameter container provides storage to give the operator easy access to the manual at the front of the machine. It is made out of a durable polyethylene and will keep the manual clean and dry in all weather conditions.
The container was designed exclusively for John Deere and the John Deere logo is shown on the lid.
Depth control
Option 1 | Tractor 3-point hitch |
Fold
Type | Non-fold (integral) |
Frame
Tubing | 4 x 4 high strength, box beam steel cross members, 2 x 4 steel end tubes, welded construction in. |
Fore-and-aft | 72 in. |
Underframe clearance | Rigid and TruPosition- 28, Tru-Depth - 32 in. |
Ground-engaging components
Choices | Variety of sweeps, shovels, and chisel points |
Horsepower required
Horsepower per foot | 6 to 10 - rigid and spring-reset standards; 6 to 14 - Tru-Depth standards hp/ft |
No basket harrows
Option 1 | Rank spacing 12 in.Spike/coil dimensions 12 in. 3-bar coil tine |
Operating speed
Miles per hour | 5 to 7 mph |
Operation depth
Maximum depth | 12 in. |
Standard options
Option 1 | Spec 1-1/4 x 2 x 28 in.Maximum operating depth 8 in.Underframe clearance 28 in.Spacing 12,16 Rigid standard |
Option 2 | Spec 1-1/4 x 2 x 28 in.Trip force 550 lbTrip height 10 in.Maximum operating depth 12 in.Underframe clearance 28 in.Spacing 12 TruPosition standard |
Option 3 | Spec 2 x 1-1/4 x 32 in.Trip force 1250 lbTrip height 11 in.Maximum operating depth 12 in.Underframe clearance 32 in.Spacing 12,16 Tru-Depth standard |
Standard spacings
Inches | 12 in. |
Transport width
Rigid frame | Option 1 9, 10 to 19, 7 ft, in. |
Wheels
Stabilizer wheels | Option 1 Stabilizer wheel frames with 5.90 - 15 4PR implement tires (Optional on 8-ft. base models, std. on 16-ft. base models |
Working widths
Rigid frame | Option 1 8 to 20 ft |
