John Deere DH56 Series Offset Disks
Agriculture
- Working widths range from 10-ft. to 14.5-ft.
- Up to 868 Lb. of cutting force per blade
- Large gang axles for strength
- Oil bath tapered roller bearings minimize maintenance
| Working - Approximate working width | 3 m 10 ft |
|---|---|
| Weight - Weight per disk blade | 393.7 kg 868 lb |
| Transport - Wheel hub bearings | Dual tapered roller bearings |
| Disk gangs - Rear angle | 3 positions |
| Lighting and safety - Safety tow chain | Yes |
| Disk gangs - Axle size | 6.4 cm 2.5 in. |
| Frame - Tube size | 20.3x20.3x1.3 cm 8x8x0.5 in. |
| Tires - Type | 2 - Radial Industrial |
| Disk gangs - Scrapers | Adjustable |
| Disk blades - Quantity | 16 |
| Tires - Size | 385/65R22.5 |
| Hitch - Front hitch type | Pintle |
| Frame - Duty | Heavy |
| Warranty - Time period | 1 year |
| Disk gangs - Bearing standards | Welded, reinforced |
| Lighting and safety - Markings | SMV |
| Lighting and safety - Lights | Yes |
| Disk gangs - Axle material | Round heat treated alloy steel threaded on both ends |
| Set-up time - Labor hours | For two people: 2-3 hours |
| Frame - Type | Single offset rigid |
| Tires - Wheel hub type | 5-spoke Dayton hubs |
| Tractor requirements - Recommended drawbar hp range | 167.8 kW 225+ hp |
| Disk gangs - Bearing wear plates | Standard |
| Available blade sizes - Blade option one | 914x12.7 mm 36x0.5 in. |
| Disk gangs - Bearing type | Oil bath tapered roller |
| Disk blades - Spacing | 43.2 cm 17 in. |
| Transport - Width | 3.4 m 11 ft |
| Weight - Net | 6,304.9 kg 13,900 lb |
| Disk gangs - Front angle | 3 positions |
| Key Specs - Disk blades | |
| Disk blades - Type | Notched (front) Notched (rear) Standard |
| Key Specs - Frame |
Featured List
- PTO HP: 225+ hp (167.8+ kW)
- Working Width: 10ft. (3.0 m)
- Hitch: Cast link
Featured Content
Minimal maintenance increases work hours
Sealed with industrial-grade seals
Oil bath tapered roller bearings, sealed with industrial-grade seals, keep maintenance to a minimum and profitable working hours at a maximum. The bearings come complete with a wear plate.
Scrapers clean disk blades
Scrapers work great in wet and sticky soils
Adjustable disk blade scrapers keep disk blades clean and performing in wet and sticky soils for increased productivity.
Keeping gangs tightened increases wear life
Gang nut wrenches are always there when needed
End washers help keep the gang shaft end nut tightened during operation, increasing gang wear life.
Two gang nut wrenches are supplied with each unit and securely attached to the unit, ready to use when the gangs need tightening.
Transport locks secure disk wings cylinder
Transport locks are standard, ensuring disk wings are in secure transport mode.
Control arms level in ground and during transport
Easy to set for desired soil condition
Two separate control arms are standard, one for transport leveling and one for leveling while the disk is in the ground. Once set for a given soil condition, the disk will continue to perform with consistency.
