John Deere DH55 Series Offset Disks
Agriculture
- Adjustable disk blade scrapers
- Oil bath tapered roller bearings minimize maintenance
- Working widths from 10-ft. to 13.75-ft.
| Tires - Type | 2 - Radial industrial |
|---|---|
| Transport - Wheel hub bearings | Dual tapered roller bearings |
| Available blade sizes - Blade option one | 813x12.7 mm 32x0.5 in. |
| Disk blades - Quantity | 20 |
| Disk gangs - Rear angle | 3 positions |
| Lighting and safety - Safety tow chain | Yes |
| Disk gangs - Axle size | 6.4 cm 2.5 in. |
| Frame - Tube size | 20.3x20.3x1.3 cm 8x8x0.5 in. |
| Disk gangs - Scrapers | Adjustable |
| Tires - Size | 385/65R22.5 |
| Weight - Net | 5443.1 kg 12000 lb |
| Tires - Wheel hub type | 5-Spoke dayton hubs |
| Hitch - Front hitch type | Pintle |
| Frame - Duty | Heavy |
| Warranty - Time period | 1 year |
| Weight - Weight per disk blade | 272.2 kg 600 lb |
| Transport - Width | 3.7 m 12 ft |
| Lighting and safety - Markings | SMV |
| Lighting and safety - Lights | Yes |
| Disk blades - Spacing | 35.6 cm 14 in. |
| Disk gangs - Axle material | Round heat treated alloy steel threaded on both ends |
| Disk gangs - Bearing standards | Welded, Reinforced |
| Frame - Type | Single offset rigid |
| Tractor requirements - Recommended drawbar hp range | 167.8 kW 225+ hp |
| Disk gangs - Bearing wear plates | Standard |
| Working - Approximate working width | 3.4 m 11 ft |
| Disk gangs - Bearing type | Oil bath tapered roller |
| Set-up time - Labor hours | 2-3 for two people |
| Disk gangs - Front angle | 3 positions |
| Disk blades - Type | Notched (front) Notched (rear) Standard |
Featured List
- Hitch: Cast link
- PTO HP: 200+ hp (149.1+ kW)
- Working Width: 10 ft. (3.0 m)
Featured Content
Scrapers clean disk blades
Scrapers work great in wet and sticky soils
Adjustable disk blade scrapers keep disk blades clean and performing in wet and sticky soils for increased productivity.
Transport locks secure disk wings cylinder
Transport locks are standard, ensuring disk wings are in secure transport mode.
Minimal maintenance increases work hours
Sealed with industrial-grade seals
Oil bath tapered roller bearings, sealed with industrial-grade seals, keep maintenance to a minimum and profitable working hours at a maximum. The bearings come complete with a wear plate.
Control arms level in ground and during transport
Easy to set for desired soil condition
Two separate control arms are standard, one for transport leveling and one for leveling while the disk is in the ground. Once set for a given soil condition, the disk will continue to perform with consistency.
Keeping gangs tightened increases wear life
Gang nut wrenches are always there when needed
End washers help keep the gang shaft end nut tightened during operation, increasing gang wear life.
Two gang nut wrenches are supplied with each unit and securely attached to the unit, ready to use when the gangs need tightening.
