John Deere XUV865M Diesel
  • + Expand All
  • - Close All
  • Conquer tough terrain with confidence

    You will feel confident and comfortable, even on tough terrain, with a full-size Gator™ Utility Vehicle. You will feel stable with a low center of gravity and a wide stance. Engine braking and four-wheel hydraulic disc brakes keep you in control on steep descents, even when fully loaded. The power steering on M- and R-Trim vehicles, is smooth and responsive.

    Standard four-wheel drive with rear differential lock
    Dash mounted four-wheel drive and rear differential lock switches Dash mounted four-wheel drive and rear differential lock switches

    With standard four-wheel drive and rear differential lock, both instantly available with the flip of a switch, you can get where you are going.

    Dual A-arm front and rear independent suspension
    Rear suspension and ground clearance Rear suspension and ground clearance

    The independent suspension provides a smooth ride as 203 mm (8 in.) of front suspension travel and 229 mm (9 in.) of rear suspension travel cushions bumps and glides over ruts. And clearing rocks and roots is no problem with 284 mm (11.2 inches) of ground clearance.

    Tires for any terrain
    Terra Hawk all-terrain tire Terra Hawk all-terrain tire
    Maxxis® Bighorn® 2.0 extreme terrain radial tire Maxxis® Bighorn® 2.0 extreme terrain radial tire
    Predator Heavy-Duty all-terrain radial tire Predator Heavy-Duty all-terrain radial tire

    Full-Size Gator Utility Vehicles are available with three tire options:

    • Terra Hawk all-terrain tires
      • Tread pattern and wide footprint provide excellent traction with minimal impact on terrain
    • Maxxis Bighorn 2.0 extreme terrain radial tires
      • Radial construction provides shock absorption, allowing for a smoother ride
      • Non-directional tread pattern provides predictable cornering and claws up roots and rocks
    • Predator Heavy-Duty all-terrain radial tire
      • Radial construction provides shock absorption, allowing for a smoother ride
      • Flat profile increases footprint area, reducing ground pressure
      • 8-ply rating delivers up to three times the life of Bighorn tires



    Maxxis® Bighorn® is registered trademark of Cheng Shin Rubber Ind. Co., Ltd.

  • Room for you, plus two

    When you hop into the seat of a full-size Gator™ Utility Vehicle, you will notice there’s seating for you, plus two.

    Three-passenger seating with room to spare
    40/60 split three-passenger bench seat 40/60 split three-passenger bench seat
    Operator platform Operator platform

    The adjustable operator’s seat and tilt steering lets drivers of all sizes get comfortable, and the passenger grab handles help everyone feel secure. The low step height and generous opening between seat base and fender is even designed to accommodate bulky work boots.

    Roof, windshield, rear panel, door, and heater options
    XUV835M with optional half doors, roof, windshield, and rear panel XUV835M with optional half doors, roof, windshield, and rear panel
    XUV865M with optional cab doors with roll down windows, roof, windshield, and rear panel XUV865M with optional cab doors with roll down windows, roof, windshield, and rear panel

    Roof, windshield, rear panel, and half doors attachments keep you dry, shaded, and out of the dust. Cab doors with roll down windows and heater attachments keep you warm all winter.

  • Go further between fill ups
    Large fuel tank fill opening Large fuel tank fill opening

    Full-size Gator™ XUVs have a large 42.8-L (11.3-gal.) fuel tank so you go further between fill ups. A 76-mm (3-in.) diameter fill opening reduce spills.

  • Color options and styling
    Green and yellow XUV835R Signature Edition with included Ultimate Protection Package Green and yellow XUV835R Signature Edition with included Ultimate Protection Package
    Olive and black XUV865M with cab and optional brush guard Olive and black XUV865M with cab and optional brush guard
    TrueTimber® KANATI camo XUV865R with optional Premium Protection Package TrueTimber® KANATI camo XUV865R with optional Premium Protection Package
    Desert sand, XUV835M Honor Edition with included brush guard Desert sand, XUV835M Honor Edition with included brush guard

    You will get noticed with the distinctive styling of full-size Gator™ XUVs. Available in four colors, with various protection packages, and more than 100 attachments, you can create a custom look that will turn heads.



    TrueTimber is a trademark of True Timber Outdoors Holding Company, LLC.

  • Automotive-like controls
    Instrument display, shift lever, and switches (shown on XUV835R Signature Edition) Instrument display, shift lever, and switches (shown on XUV835R Signature Edition)

    When you sit behind the wheel of a full-size Gator™ Utility Vehicle, you will be reminded of your favorite pick-up truck. There are controls at your fingertips, an easy-to-read instrument panel, and outlets to recharge your phone.



    Shift from park and into gear with a throw of a single lever. Power steering on M- and R- trim vehicles is smooth and responsive.



    When the going gets tough, you can instantly engage four-wheel drive and rear differential lock with switches. Even at night, the backlit switches are easy to see. If a front wheel starts to slip, the front differential automatically locks to pull you through.

  • Durable, fuel-efficient diesel-powered drivetrain
    854-cc (52.1-cu in.) diesel engine and drivetrain 854-cc (52.1-cu in.) diesel engine and drivetrain

    The XUV865 and XUV825M S4 Gator™ Utility Vehicles are powered by a fuel-efficient and durable diesel engine. The enclosed drivetrain automatically adjusts for fast acceleration, along with powerful hauling and hill-climbing capabilities. With plenty of torque to get the job done, this engine will provide reliable performance for years to come.

  • Built for the long haul

    Full-size Gator™ XUVs are built to work hard and go the extra mile.

    Heavy-duty frame
    Underside view of XUV865M Underside view of XUV865M
    Underside view of XUV825M S4 Underside view of XUV825M S4

    The hefty frame is designed to stand-up to all the bumps and bends of the trail, and the standard front skid plate protects key components from damage.

    Constant velocity boot protection
    Constant velocity boot protection Constant velocity boot protection

    Constant velocity joints are enclosed to keep water and dirt out. A protector shield protects the boot from trail debris.

    Automotive-grade panels and optional protection packages
    TrueTimber® KANATI camo XUV865R with optional Premium Protection Package TrueTimber® KANATI camo XUV865R with optional Premium Protection Package

    The hood and side panels are made of automotive-grade materials that resist scratches and dents, and the cargo box is made of tough composite material that resists dents and rust. Optional protection packages look tough and provide even more protection.



    TrueTimber® is a trademark of True Timber Outdoors Holding Company, LLC.

  • Store more gear

    One-row full-size Gator XUVs come packed with places to store tools, gear, and beverages.

    Cup holders
    Four cup holders and center tray (shown on XUV835E) Four cup holders and center tray (shown on XUV835E)
    Cab door cup holder and pocket Cab door cup holder and pocket

    The dash has four cup holders, and cab vehicles have a cup holder in each door.

    Dash and under-seat storage
    Under seat storage (shown on XUV835E) Under seat storage (shown on XUV835E)
    Glove box, storage pocket, and two dash bins (shown on XUV835M cab) Glove box, storage pocket, and two dash bins (shown on XUV835M cab)

    The vehicles also feature an enclosed glove box, center tray, dash storage pocket and under-seat storage. Depending on the configuration, vehicles may have up to three additional dash bins and under-hood storage.

  • Haul more in fewer trips

    The full-size Gator™ XUV can haul 454 kg (1000 lb), so load it up with confidence. You can also make fewer trips with 1814 kg (4000 lb) of towing capacity and a standard 51-mm (2-in.) receiver hitch.

    Built-tough cargo box
    Cargo box (shown with spray-in liner and optional taillight protectors) Cargo box (shown with spray-in liner and optional taillight protectors)
    Cargo box converted to flatbed Cargo box converted to flatbed

    The cargo box resists dents, scratches, and rust because it is made from a tough composite material. You will have no problem securing loads with integrated tie bars and 14 tie-down points. You can also convert the cargo box to a flatbed when you need to haul big and bulky loads.



    The cargo box measures 1143 mm (45 in.) long, 1320 mm (52 in.) wide, and 305 mm (12 in.) deep.

    One-handed tailgate
    Tailgate handle Tailgate handle

    Since your hands are always full, the tailgate can be opened and closed with one hand. You can also lower the tailgate to carry longer items or remove it for easy cleanout.

    Power lift
    Deluxe cargo box unloading rocks Deluxe cargo box unloading rocks

    To save your back, the optional cargo box power lift empties heavy loads with the push of a button.

Brakes

Park brake Park in-transmission, Optional factory-installed secondary foot operated with hand release
Type Front/rear hydraulic disc with twin piston front calipers
