John Deere 6120R vs. 6140M

The 6120R and the 6140M are both fantastic pieces of equipment. They share a number of similarities but have a few key differences, too. We’ll go over those differentiators to help you make the right decision for you and your property.

Get a Quote

See the Difference

Compare Models

SPECS John Deere 6120R John Deere 6140M
Key Specs - Rated engine power 97/68EC: 88 kW
120 hp
81 kW
140 hp
w/ IPM: 118 kW
160 hp
Key Specs - Rated PTO power (hp SAE) 70 kW
94 hp
80 kW
109 hp
Key Specs - Transmission type Standard: 20 Speed AutoQuad PLUS™ ECO (40K)
Optional: 16 speed PowerQuad PLUS™
20 speed AutoQuad PLUS™ ECO (50K)
Infinitely variable transmission (IVT) 0.050-42 km/h
0.030-26 mph
Infinitely variable transmission (IVT) 0.050-50 km/h
0.030-31 mph
Standard: John Deere 24-speed PowrQuad™ Plus 40 km/h
Optional: John Deere 16-speed PowrQuad Plus 30 km/h
John Deere 24-speed AutoQuad™ Plus 40 km/h
John Deere 24-speed CommandQuad™ Plus 40 km/h
AutoPowr™/IVT™ 40 km/h
Creeper (PowrQuad Plus and AutoQuad Plus)
Key Specs - Rear hitch category (SAE designation) Standard: Category 2/3N: 2532 kg
5582 lb
Optional: Category 2/3N: 3371 kg
7432 lb
3N
Key Specs - Hydraulic pump rated output Standard: 45 cc pump: 114 L/min
30 gpm
Standard: 35-cc pump: 80 L/min
21 gpm
Optional: 45-cc pump: 114 L/min
30 gpm
Front hitch - Standard lift capacity 4400 kg
9700.3 lb
Dimensions - Wheelbase 2WD and MFWD: 2580 mm
102 in.
2580 mm
101.6 in.
See Complete 6120R Specs See Complete 6140M Specs
