John Deere 5075GN Tractor
Agriculture
- Perfect for the narrower rows producers are moving toward to conserve water
- Working width of 49.5”
- FT4 75 hp engines/61 hp PT
- Two transmissions available: 12F/12R and 24F/12R
| Key Specs - Transmission type | 24F/12R PowrReverser, EH Hi-Lo |
|---|---|
| Transmission - Type | 24F/12R PowrReverser, EH Hi-Lo |
| Transmission - Clutch; wet/dry | Wet |
| Engine specifications - Engine family | FPTF34 |
| Rear axle - Axle type | Flanged |
| Engine specifications - Cylinders liners | Wet sleeved |
| Operator station - dB(A) rating | 82 |
| Engine specifications - After treatment type | Diesel Oxidation Catalyst (DOC) and diesel Particulate Exhaust Filter (DPF) |
| Rear axle - Brakes, type and control | Multi-disc rear braking |
| Serviceability - Interval for engine oil change | 500 |
| Rear power take-off (PTO) - Type | Standard: 540/540E |
| Key Specs - Rear hitch category (SAE designation) | Category 1/Category 2 |
| Electrical system - Alternator size | 120 amp |
| Rear axle - Type | Carraro Drivetech |
| Rear axle - Differential controls | Multi disk oil cooled design |
| Hydraulic system - Type | Open Center |
| Rear hitch - Hitch draft control load sense type | Mechanical |
| Tires - Rear | 280/70 R18 |
| Engine specifications - Aspiration | Wastegate Turbocharger with intercooler and eventually cooled Exhaust Gas |
| Rear power take-off (PTO) - PTO actuation | Electrohydraulic |
| Steering - Type | Dynamic Load Sensing, Hydrostatic, Flow Metering |
| Serviceability - Interval for hydraulic/transmission oil change | 750 |
| Transmission - Creeper | Yes |
| Rear hitch - Sensing type | Top Link Draft Sensing |
| Engine specifications - Rated speed | 2300 rpm |
| Tires - Front | 7.50R16 |
| Front axle - Front axle differential lock | Self Locking Differential |
| Rear axle - Final drive type | Three point inboard planetary drives |
| Rear axle - Rear differential lock | Electrohydraulic |
| Hydraulic system - SCV control | Mechanical |
| Front axle - Type | Carraro Drivetech |
| Rear hitch - Hitch category (SAE designation) | Category 1/Category 2 |
| Drawbar - Drawbar category | Extendable |
| Transmission - Reverser | Yes |
| Engine specifications - Emission level | Final Tier 4 |
| Key Specs - Hydraulic pump rated output | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 L/min 33.4 gpm |
| Engine performance - Rated power | 54.4 kW 73 hp |
| Operator station - Seat | OOS: standard: COBO MT SC74 M200 Optional: COBO MT SC74 M97 Cab: standard: COBO MT SC74 M200 Optional: GRAMMER MSG93/511 |
| Capacities - Fuel tank | Standard: 85.9 L 22.7 U.S. gal. Optional: 114.3 L 30.2 U.S. gal. |
| Weight - Maximum permissible weight | 4200 kg 9259.41 lb |
| Engine performance - Rated PTO power (hp SAE) | 45.5 kW 61 hp |
| Dimensions - Wheelbase | 2098 mm 82.5 in. |
| Engine specifications - Displacement | 4 cylinder: 3.4 L 207 cu in. |
| Dimensions - Front axle center | Min. 254 mm 10 in. Max. 289 mm 11.3 in. |
| Rear power take-off (PTO) - Engine rpm (at rated PTO speeds) | 540 at 1938 rpm 540E at 1648 rpm |
| Key Specs - Engine displacement | 4 cylinder: 3.4 L 207 cu in. |
| Tires - Turning radius without brakes | 3627 mm 11.9 ft |
| Hydraulic system - Available flow at a single rear SCV | 66.2 L/min 17.6 gpm |
| Key Specs - Rated PTO power (hp SAE) | 45.5 kW 61 hp |
| Hydraulic system - Pump rated output | Standard: 96.5 L/min 25.5 gpm Optional: 126.4 33.4 gpm |
| Engine specifications - Description | 3.4L Fiat® Powertrain Technologies |
| Key Specs - Engine description | 3.4L Fiat® Powertrain Technologies |
| Dimensions - Drawbar clearance | Min. 254 mm 10 in. Max. 289 mm 11.3 in. |
| Operator station - Rollover protective structure, OOS | Rigid - foldable - telescopic Rigid, front folding Platform - flat/straddle Straddle Gearshift location - console/floor Floor Yes |
| Key Specs - Rated engine power | 54.4 kW 73 hp |
| Key Specs - Base machine weight | OOS: 2660 kg 5864 lb Cab: 2975 kg 6558 lb |
| Hydraulic system - Number of rear selective control valves (SCVs) | Standard: 2 Optional: 4 |
| Weight - Base machine weight | OOS: 2660 kg 5864 lb Cab: 2975 kg 6558 lb |
| Rear hitch - Maximum lift capacity behind lift points | 2549 kg 5620 lb |
| Dimensions - Overall length | 4319 mm 170 in. |
Featured List
- Open Station: Yes
- Cab: Yes
- Engine HP: 75 hp
- Optional Transmission:
24F/12R PowerReverser
- Standard Transmission:
12F/12R SyncReverser
Featured Content
The 5G Final Tier 4 (FT4) Specialty Series now brings a narrow, ultra-narrow, and low-profile option to specialty applications.
The 5GV Series is built to operate in vineyards with a minimum working width of 108.8 cm (42.8 in.) from rear tire to rear tire. The 5GV Series cab, with an overall width of 108.1 cm (42.6 in.), is designed to pass between narrow vineyard rows. The 5GN features an extra- wide cab of 127.5 cm (50.2 in.). The 5GL series is manufactured with orchardists in mind. This low-profile tractor has an approximate height of 135.89cm (53.5 in.) and width of 152.4cm (60 in.) (depending on tire configuration), which makes it ideal for operating in orchards that are laden with heavy fruit.
The two-door cab on the 5GN and 5GV models offers the operator yet another convenience of entering and exiting from either side. With a distance of 560 mm (22.1 in.) between the right- and left-hand side consoles and a play of 285 mm (11.2 in.) between seat and steering wheel, the 5G Series provides one of the roomiest cabs in the specialty tractor market.
Overview of minimum working widths
Overview of minimum working widths
5G Specialty Series basic feature overview:
| Feature overview | 5GN | 5GV | 5GL |
| 100 hp (74 kW), 4-cylinder / 3.4 L (0.9 gal.) | 5100GN | N/A | N/A |
| 90 hp (63 kW), 4-cylinder / 3.4 L (0.9 gal.) | 5090GN | 5090GV | N/A |
| 75 hp (55 kW), 4-cylinder / 3.4 L (0.9 gal.) | 5075GN | 5075GV | 5075GL |
| Two-wheel drive (2WD) / four-wheel drive (4WD) | Only 4WD | Only 4WD | Only 4WD |
| Cab / open operator station (OOS) | Available | Available | Only OOS |
5GV cab on 5GN Tractor
The 5G Series has also expanded its platform offerings to include a 5GV cab on a 5GN Tractor. This option combines the fit of 5GV with the wider stance of a 5GN, providing excellent stability paired with the narrowest cab offering available in the 5G portfolio.
John Deere value
Performance: tailored to fit – matching narrow widths and low heights to producers’ high value crop applications.
The heavy-duty 3-point hitch design on the 5G Series provides a standard maximum lift of 2590 kg (5,710 lb) at the ball ends. An optional additional lift cylinder is available for the 5GN Series, which increases the maximum lift capacity by 510 kg (1,124 lb) to 3100 kg (6,834 lb) at the ball ends.
Hooking up implements is quick and simple with the standard Category 2 3-point hitch on the 5GN. Hooking up implements that require Category 1 or Category 1N is also possible and requires very little time with the 5GV and 5GL.
Optional extra lift capacity shown on the 5GN photo
| Code | Description | Information | Availability |
| 8490 | Additional lift cylinder | Includes additional lift cylinder (maximum lift capacity at ball ends: 3100 kg [6,834 lb]) | 5GN |
| 4130 | Fixed ball ends | 3-point hitch with fixed ball ends for draft links | 5GN, 5GV |
| 4131 | Adjustable ball ends | 3-point hitch with adjustable ball ends for draft links | 5GN, 5GV |
| 4132 | Adjustable quick couplers | 3-point hitch with adjustable quick couplers for draft links | 5GN, 5GV, 5GL |
| 4151 | Hydraulic lift rod | Hydraulically adjust lift arm to tilt or level implement | 5GN, 5GV, 5GL |
| 4152 | Mechanical lift rod | Mechanically adjust lift arm to tilt or level implement | 5GN, 5GV, 5GL |
Lift rods
John Deere value
Performance: higher lift capacity for a wider variety of implements and strong performance means real versatility.
The 5G Series Tractors are heavy-duty utility tractors in two narrow chassis widths. Heavier gross vehicle weight means more down force to keep implements in the ground. Heavier equipment also leads to improved traction and performance in the field. The 5G Series Tractors have the weight to power through tough jobs.
| Machine | Four-wheel drive (4WD) rollover protective structure (ROPS) | 4WD cab |
| 5075GV | 2530 kg (5577 lb) | 2745 kg (6051 lb) |
| 5090GV | 2530 kg (5577 lb) | 2745 kg (6051 lb) |
| 5075GN | 2660 kg (5864 lb) | 2975 kg (6558 lb) |
| 5090GN | 2660 kg (5864 lb) | 2975 kg (6558 lb) |
| 5100GN | 2660 kg (5864 lb) | 2975 kg (6558 lb) |
| 5075GL | 2670 kg (5886 lb) | No cab option |
The John Deere 5G Series provides an outstanding total hydraulic system flow of 126.4 L/min (33.4 gpm) with an optional third hydraulic pump.
This hydraulic system ensures excellent hydraulic performance and capacity:
- Precise steering without diverting oil flow from the selective control valves (SCVs) and rockshaft is ideal when maneuvering and operating an implement at the same time as turning at the headland
- Ensures easy power steering with heavy loads on the front of the tractor
- Supplies plenty of power to run hydraulic motors
- Fast cycle times even during the simultaneous usage of various hydraulic driven implements
|
Hydraulic performance |
5075GV | 5090GV | 5075GN | 5090GN | 5100GN | 5075GL |
| Steering and transmission | 29.9 L/min (7.9 gpm) | |||||
| Second pump – SCV and hitch | 66.6 L/min (17.6 gpm) | |||||
| Third pump – rockshaft | 29.9 L/min (7.9 gpm) | |||||
| Total hydraulic flow | 126.4 L/min (33.4 gpm) | |||||
The 5G Specialty Series Tractors are equipped with powerful FT4 diesel engines.
All GN, GV, and GL models are equipped with a robust FPT Industrial 4-cylinder, 3.4-L (207.5-cu in.) displacement engine that offers real versatility and performance for all kinds of specialty operations.
| Engine overview | 5GN | 5GV | 5GL |
| 74.6 kW (100 hp), 4-cylinder / 3.4 L (207.5 cu in.) | 5100GN | Not available | Not available |
| 67.1 kW (90 hp), 4-cylinder / 3.4 L (207.5 cu in.) | 5090GN | 5090GV | Not available |
| 55.9 kW (75 hp), 4-cylinder / 3.4 L (207.5 cu in.) | 5075GN | 5075GV | 5075GL |
Supporting the narrow dimensions of the 5GV Series
The narrow width of the 5GV Series requires a compact engine solution. The compact 3.4-L (207.5-cu in.) engine supports the envelope of the 5GV Series entering super narrow vineyards as well as the turning radius at the end of a row.
Performance – made to measure
The engine ensures high productivity under tough working conditions. With a torque of 401 Nm (295.7 lb-ft) for the 74.6-kW (100-hp) model, the engine ensures the optimal performance for versatile operations.
John Deere value:
Performance: the powerful FT4 engines support the narrow machine envelope of the 5G Specialty Series and offer a high torque at rated rpm, which provides a high performance.
The 5GN models have an optional auxiliary fuel tank available, which increases the fuel tank capacity by up to 38 percent on the 5075GN and up to 33 percent on the 5090GN and 5100GN.
The increased capacity allows for more productive time in the field with fewer stops for refueling.
| Machine | Code | Fuel tank capacity | Code | Auxiliary tank capacity |
| 5075GN | Base | 86 L (22.7 gal.) | 8313 | 28.4 L (7.5 gal.) |
| 5090GN | Base | 73 L (19.3 gal.) | 8313 | 28.4 L (7.5 gal.) |
| 5100GN | Base | 73 L (19.3 gal.) | 8313 | 28.4 L (7.5 gal.) |
Auxiliary fuel tank
The 5G Series comes standard with a 24 forward/12 reverse (24F/12R) PowrReverser™ transmission. The 24F/12R transmission provides 24 forward speeds and 12 reverse speeds for transport speeds of up to 40 km/h (24.9 mph). The transmission provides convenient Hi-Lo and declutch push-button controls. The Hi-Lo feature benefits operators who frequently transport their tractors from field to field or find themselves in bog-down situations during rear power take-off (PTO) work.
Users can push the rabbit button (high) without having to depress the clutch to get an increase in speed. They can also push the turtle button (low) to get a decrease in speed, similar to downshifting or engine braking without having to grab another gear. The PowrReverser transmission has a built-in engagement override valve for additional safety. This valve requires the clutch pedal to be depressed one time after each engine start before the transmission will begin to operate normally, giving the operator another opportunity to put all focus on the tractor. A neutral start switch requires the PowrReverser lever to be in the neutral position to start the engine.
Gear-shift lever with Hi-Lo selectors
| 24F/12R PowrReverser | |
| Speed (km/h) | 0.5 to 40 km/h (0.3 to 24.9 mph) |
| Creeper range | Yes |
| Configuration | Four-wheel drive (4WD) |
| Clutch type | Multi-disc wet clutch |
| Clutching required to shift | No |
| Reverser | PowrReverser |
| Hi-Lo | Electrohydraulic |
| Mechanical front-wheel drive (MFWD) engagement | Electrohydraulic, if MFWD option installed |
| PTO engagement | Electrohydraulic |
| Differential lock engagement | Electrohydraulic |
Regular service and maintenance are essential to the performance, productivity, and longevity of the tractor.
- Easy access to regular service points minimizes service time.
- Tractors are equipped with onboard self-diagnostic capabilities and are fully compatible with the John Deere-exclusive Service ADVISOR™ system.
- Daily service requirements are minimal and simple to accomplish. Most service interval requirements can be performed with a basic understanding of procedures and common tools.
All items in the daily service schedule can be performed without the use of tools:
- Convenient access to engine oil, hydraulic oil, coolant level, and water separator
- Easy access to periodic engine maintenance checks by simply raising the hood
- Single-point latch mechanism and self-contained leash ensure easy hood opening and closure
NOTE: Always refer to the operator’s manual for complete maintenance and service recommendations.
