John Deere GM40E Series Grooming Mowers
Agriculture
Maintain a clean and level look with efficient Grooming Mowers. Designed to give a smooth cut on lawns, sporting fields, and golf courses.
- Caster wheels follow ground contours and prevent scalping
- Floating hitch for level cutting
- High blade-tip speed
- Rugged gearbox with cooling fins
- iMatch™ quick-hitch compatible with conversion kit
| Blade - Tip speed, average fpm | GM4060E: 5455.9 m/min 17900 fpm GM4072E: 5486.4 m/min 18000 fpm |
|---|---|
| Key Specs - Overall machine width | GM4060E: 155.2 cm 61.1 in. GM4072E: 185.7 cm 73.1 in. |
| Key Specs - PTO horsepower | GM4060E: 11.2-26.1 kW 15-35 hp GM4072E: 18.6-26.1 kW 25-35 hp |
| Warranty - Machine | All GM40E: 1 year |
| Blade - Composition | All GM40E: Heat treated alloy steel |
| Blade - Spindles | Quantity All GM40E: Three Composition All GM40E: Cast iron Bearing All GM40E: Ball bearing |
| Key Specs - Cutting height | All GM40E: 3.8-12.7 cm 1.5-5 in. |
| Caster wheels - Solid | Size All GM40E: 20.3x8.9 cm 8x3.5 in. All GM40E: Yes |
| Blade - Quantity | All GM40E: Three |
| Tractor requirements - PTO rpm | All GM40E: 540 rpm |
| Deck - Thickness | All GM40E: 10 gauge 3.416 mm 0.1345 in. |
| Key Specs - PTO rpm | All GM40E: 540 rpm |
| Dimensions - Overall machine width | GM4060E: 155.2 cm 61.1 in. GM4072E: 185.7 cm 73.1 in. |
| Key Specs - Blade - Quantity | All GM40E: Three |
| Hitch - Category | GM4060E: Category 1 and Limited Category 1 GM4072E: Category 1 |
| Key Specs - Deck - Thickness | All GM40E: 10 gauge 3.416 mm 0.1345 in. |
| Gearbox - Mower deck horsepower | All GM40E: 26.1 kW 35 hp |
| Set-up time - Labor hours | All GM40E: 0.5 |
| Dimensions - Cutting height | All GM40E: 3.8-12.7 cm 1.5-5 in. |
| Warranty - Gearbox | All GM40E: 3 year |
| Key Specs - Hitch - Category | GM4060E: Category 1 and Limited Category 1 GM4072E: Category 1 |
| Deck - Discharge | All GM40E: Rear |
| Belts - Type | All GM40E: One |
| Blade - Overlap | All GM40E: 3.18 cm 1.25 in. |
| Weight - Shipping | GM4060E: 254.9 kg 562 lb GM4072E: 279 kg 615 lb |
| Caster wheels - Quantity | All GM40E: Four |
| Dimensions - Cutting width | GM4060E: 152.4 cm 60 in. GM4072E: 182.9 cm 72 in. |
| Gearbox - Ratio | All GM40E: 1:1.9 |
| Key Specs - Cutting width | GM4060E: 152.4 cm 60 in. GM4072E: 182.9 cm 72 in. |
| Blade - Dimensions | All GM40E: 0.6x6.4 cm 0.25x2.5 in. |
| Belts - Quantity | All GM40E: Spring loaded idler |
| Weight - Operational | GM4060E: 218.2 kg 481 lb GM4072E: 244 kg 538 lb |
| Key Specs - Deck - Discharge | All GM40E: Rear |
| Tractor requirements - PTO horsepower | GM4060E: 11.2-26.1 kW 15-35 hp GM4072E: 18.6-26.1 kW 25-35 hp |
| Key Specs - Caster wheels - Solid | All GM40E: Yes |
Featured List
- PTO HP: 15 – 50 hp (11.2 – 37.3 kW)
- Working Width: 60 in. (152.4 cm)
- Hitch: Cat. 1 and Ltd. Cat. 1
Featured Content
Prevents debris from flying out from under deck
A rear chain shield kit is available as an attachment for field conversion. It assists in preventing debris from flying out from underneath the deck of the rear-discharge grooming mowers.
Provides a quality cut
High blade-tip speed and precise blade overlap work together to ensure exceptional strength, performance, and a quality cut.
Three blades per deck
To meet specific mowing needs, choose from two blade types:
- Low lift
- High lift (standard)
Smooth, level finish
The floating top link on the GM40E Series keeps the deck tracking over ground contours for a level and smooth cut.
Four caster wheels follow ground contours
By having four caster wheels, the GM40E Series Grooming Mower follows ground contours and prevents scalping. Heavy tubular caster wheel arms are bolted to rail supports for long life.
Gearbox is rated for up to 35 hp for longer life
The GM40E Series Grooming Mowers come with a 35 hp rated rugged gearbox.
Deck design increases overall productivity
The deep deck design allows greater cutting volume and a cleaner cut. Offset Gauge Wheels are reducing grass tracks
An anti-scalping front roller kit can be ordered as an attachment for field conversion for FM and GM Series Grooming Mowers when not standard equipment. The roller is attached to the front of the cutting deck to help reduce scalping.
Each kit contains one roller.
An anti-scalping rear roller kit can be ordered as an attachment for field conversion for GM40E Series Grooming Mowers when not standard equipment. The roller is attached to the rear of the cutting deck to help reduce scalping.
Each kit contains one roller.
