John Deere 5090E vs. 5090M
The 5090E and the 5090M are both fantastic pieces of equipment. They share a number of similarities but have a few key differences, too. We’ll go over those differentiators to help you make the right decision for you and your property.
Get a QuoteSee the Difference
Compare Models
![]() |
![]() |
|
SPECS | John Deere 5090E | John Deere 5090M |
---|---|---|
Key Specs - Rated engine power | At 2400 per ISO 97/68/EC: 67.1 kW 90 hp |
At 2200 rpm per ISO 97/68/EC: 66.6 kW 89.2 hp |
Key Specs - Rated PTO power (hp SAE) | At 2400 per SAE: 52.2 kW 75 hp |
At 2100 rpm per SAE: 55.9 kW 75 PTO hp |
Key Specs - Transmission type | Standard: 12F/12R PowrReverser Optional: 24F/12R PowrReverser |
Standard: 16F/16R PowrReverser Optional: 12F/4R SyncShuttle Plus 32F/16R PowrReverser Plus |
Key Specs - Rear hitch category (SAE designation) | Category 2 | Category 2; convertible to 1 |
Key Specs - Hydraulic pump rated output | 85.1 L/min 22.5 gpm |
94 L/min 24.7 gpm |
Front hitch - Standard lift capacity | 1931 kg 4257 lb |
|
Dimensions - Wheelbase | MFWD: 2350 mm 92.5 in. |
2WD and MFWD: 2350 mm 92.5 in. |
See Complete 5090E Specs | See Complete 5090M Specs |
