Specifications

Capacities

Fuel tank Standard: Open: 94.6 L<br/>25 U.S. gal.<br/>Cab: 114 L/min<br/>30 U.S. gal.

Dimensions

Wheelbase MFWD: 2350 mm<br/>92.5 in.
Approximate shipping weight, Open;Cab MFWD: Open: 3300 kg<br/>7275 lb<br/>Cab: 3700 kg<br/>8150 lb

Engine performance

Rated PTO power (hp SAE) At 2400 per SAE: 52.2 kW<br/>75 hp
Rated power At 2400 per ISO 97/68/EC: 67.1 kW<br/>90 hp

Engine specifications

Cylinders liners Wet sleeved
Description John Deere PowerTech 4045
Displacement 4 cylinders: 4.5 L<br/>276 cu in.
Engine family FJDXL04.5305
Aspiration Turbocharged

Hydraulic system

Pump rated output Standard: 85.1 L/min<br/>22.5 gpm
Type Open center
Number of rear selective controls valves (SCVs) 2; up to 3
Number of mid selective controls valves (SCVs) 2; up to 3
Available flow at a single rear SCV 60.1 L/min<br/>15.9 gpm
Joystick SCV control Optional

Miscellaneous

Country of manufacture Augusta, GA (USA)

Operator station

Rollover protective structure, OOS Rigid - foldable - telescopic<br/>Foldable, 2-postPlatform - flat/straddle<br/>StraddleGearshift location - console/floor<br/>Floor
dB(A) rating 78 dBA

Rear axle

Type Inboard planetary
Brakes, type and control Hydraulic wet disc
Axle type Flanged
Differential controls Mechanical (pedal)

Rear hitch

Sensing type Top link
Hitch draft control load sense type Mechanical
Maximum lift capacity behind lift points Standard: 1457 kg<br/>3213 lb
Hitch category (SAE designation) Category 2
Remote control valves available 2; up to 3

Rear power take-off (PTO)

Engine rpm (at rated PTO speeds) 540 at 2400 rpm<br/>540E at 1716 rpm<br/>1000 at 2400 rpm
Type Standard: 540/540E<br/>Optional: 540/1000
PTO actuation Electrohydraulic

Standard tires

Front MFWD: 11.2-24 R1 Bias
Turning radius without brakes MFWD: 4.36 m<br/>14.3 ft
Turning radius with brakes MFWD: 3.54 m<br/>11.6 ft
Rear MFWD: 16.9-30 R1 Bias
Wheel tread range MFWD: front: 1340-1904 mm<br/>52.8-75.0 in.

Transmission

Clutch; wet/dry Wet
Creeper Not available
Reverser Yes
Type Standard: 12F/12R PowrReverser<br/>Optional: 24F/12R PowrReverser
