John Deere 615P

615P Belt Pickup Platform

  • John Deere
  • Belt Pickup Platforms

Find a location to get your local store information and inventory.

Find Location
Your Preferred Store
Change location Change location
Request Quote
Key Features & Specs
  • Hydraulic adjustable windscreen maximizes control
  • Dual-belt draper pickup
  • Steel auger fingers
  • Fixed gauge wheels reduce width of platform
  • Models 15 ft.
  • + Expand All
  • - Close All
  • FieldGlide™ suspension system on 615P
    615P suspension system615P suspension system
    #

    The exclusive FieldGlide suspension system features an adjustable air spring and heavy-duty hydraulic shock design to dampen movement during field operation, allowing the operator to increase harvesting speed.  Once set, the air springs do not need adjustment during the season.



    Feature benefit:

    • Improves windrow harvesting performance
    • Harvest at faster speeds
    • No tools needed
    Functionality

    Adjustment of the air springs requires no tools and is simple compared to other belt pickup suspensions. Adjust the air springs according to instructions located on the belt pickup side sheets.

  • Dual draper belts on 615P
    Crop transition on 615PCrop transition on 615P
    #



    The 615P features a dual-belt draper to enhance material flow into the combine when harvesting windrows.



    Feature benefit:

    • Smooth material flow into the auger
    • Increased material handling capacity
    • Allows crop to fall from the pickup belts
    Functionality

    The transfer belts move crop under the 66-cm (26-in.) diameter auger. This provides significant material handling advantages in large/dense windrows.

  • 615P belt tensioning system
    615P belt tensioning615P belt tensioning
    #



    The 615P features a belt tensioning system for extended belt and roller life.



    Feature benefit:

    • Belts are evenly tensioned for uniformed loading
    • Easy adjustment that requires minimal tools
    • Minimizes seed loss
  • 615P wide belts improve feeding
    615P615P
    #



    The 615P features 4.5-m (178-in.) wide belts for enhanced belt tracking with reduced seed loss.



    Feature benefit:

    • Eliminates the need for a complicated center-support roller
    • Reduces seed loss
    • Improved belt tracking
    Functionality

    Connectors between belts improve belt-drive capacity in tough windrow conditions without the need for a center support on the drive rollers. This design eliminates roller flanges which would create a gap between belts and could result in crop losses. The heavy-duty 615P belts are designed for maximum wear life.

  • Windscreen on 615P
    615P hydraulic windscreen615P hydraulic windscreen
    #

    The hydraulic windscreen on the 615P allows the operator to maximize productivity by controlling the crop flow in changing windrow conditions.



    Feature benefit:

    • Adjustments made from the cab
    • Control crop flow in changing windrow conditions
    Functionality
    Manual tilt adjustment for windscreenManual tilt adjustment for windscreen
    #

    The hydraulic windscreen utilizes double-acting cylinders which react quicker in maximizing the control of the crop. The windscreen is controlled by the fore-and-aft control on the combine hydro handle. A benefit is the header backshaft speed can be controlled independently of the windscreen allowing for increased belt pickup, and auger/feederhouse chain speed for tough windrow conditions.

Auger

Float range 57 mm
2.25 in.
Diameter 662 mm
26 in.
Auger fingers Heavy-duty, round, diameter with breakaway notch 15.9 mm
0.625 in.
Number of auger fingers 19 STS, maximum 22
Auger finger pattern In-line, retracting
Finger reach 152 mm
6 in.
Operating speed At 520 feederhouse speed 180 rpm
