LW11 Series In-Line Bale Wrapper
- John Deere
- Hay & Forage
Find a location to get your local store information and inventory.
Find Location
Key Features & Specs
- Bale push is integrated into machine
- Wrapping cycle shuts down when out of film
- 120 bales per hour
- Central control box operates all hydraulic functions
- Wrapping Capacity 120 bales / hr
- Bale Capacity 5 ft. 6 in. (1.7 m) round
- Power 13 hp (9.7 kW)

- + Expand All
- - Close All
-
Control box and levers are control center of machine
Multipurpose control center
The control box and levers are the control center of the in-line bale wrappers.
A few of the uses are to turn the unit on and off, control the bale ramp, and bale push.
-
Options available to increase productivity and uptime
14.9-kW (20-hp) Honda™ engine
A larger horsepower engine with a high-flow pump provides increased capacity to complete the job faster.
NOTE: LW Series In-Line Baler Wrappers come standard with a 9.7-kW (13-hp) Honda engine.
Honda is a registered trademark of Honda Motor Company.Single- and dual-power drive
Optional single-power drive
Optional single- or dual-power drives allow the operator to maneuver the unit without attaching it to a tractor. The single-power drive has one rear tire, while the dual-power drive has two rear tires, to provide traction for the unit. These features are great for wet or uneven ground conditions where traction is limited.
Steering remote control
Remotely stops and starts unit
This remote control allows the operator to steer, start, and the stop the machine without using the control panel on the machine.
Twin wrap kit
Twin wrap kit
This kit provides a double layer of wrap, increasing the amount of wrap applied to bales.
Bale follower
The bale follower allows the in-line wrapper to automatically follow the line of bales next to it.
Work lights
Lights allow operators to work longer hours
For early morning or late night work, choose between two optional work lights – light-emitting diode (LED) and halogen.
-
Film wrap sensor shuts down wrapping cycle when out of film
Silver rod and limit switch comprise the sensor
The film wrap sensor automatically shuts down the wrapping cycle when the machine runs out of film or breaks.
-
Adjustable tongue (hitch) folds out of way for easy repositioning of unit
Adjustable tongue (hitch)
The adjustable tongue (hitch) folds neatly out of the way for wrapping. It is located at the opposite end of where the bales are wrapped.
The adjustable tongue makes moving and repositioning the machine a quick and easy task, saving time and money.
-
Bale push is integrated into machine
Optional bale push off arm
Operator needs to extend arm
The bale push moves the bale to the back of the bale wrapper. From this point, the operator can utilize the optional bale push off arm to finish the process. The operator moves a lever to extend the arm, and the arm pushes the bale off onto the ground.
-
Traction implement tires great on wet and uneven terrain
Assist in difficult field conditions
Traction implement tires make the in-line wrappers sure-footed on wet and uneven terrain to help get the machine where it needs to be for wrapping bales.
The LW11 Series comes standard with the traction implement tires, and they are available on the LW12 Series only when ordered with single- or dual-power drive.
Bale capacity
Round bale diameter | 1.7 m 5.5 ft |
Controls
Lift mechanism | Hydraulic rear axle rotation |
Steering | Hydraulic with optional remote control |
Power drive | Optional, hydraulic single or dual wheel |
Type | Electric over hydraulic 12 V |
Hydraulic system | Self-contained |
Dimensions
Overall machine shipping length | 5 m 16.4 ft |
Overall machine width | 2.7 m 9 ft |
Overall machine length | 5.5 m 18 ft |
Overall machine height | 2.7 m 9 ft |
Final bale push off
Bale pusher | Self-contained scissor linkage |
Unloading | Manual cross tube |
Hitch
Length | Adjustable |
Type | Folding |
Lighting, marking and safety
Safety tow chain | Standard |
Jack | Standard |
Markings | SMV and reflectors |
Transport safety lights | Standard |
Power
Engine size | 9.7 kW 13 hp |
Start type | Electric |
Engine type | Honda |
Alternator size, amp | 18 amp |
Set-up time
Labor hours | 1 |
Tires
Size (rear) | 27x10.5 Traction |
Size (front) | 11L-15 Implement |
Quantity | Four (two front, two rear) |
Warranty
Machine | 1 year |
Weight
Towing unit minimum weight | 1,511.8 kg 3,333 lb |
Weight | 2,268 kg 5,000 lb |
Wrapping
Bale guide rollers | Two standard |
Wrapping capacity | 120 bales per hour |
Bale alignment | Fixed bale guides |
Cycle time | Adjustable with limit switches |
Film tensioners | Two aluminum rollers: 76.2 cm 30 in. with stretch: 55 percent |
Hoop speed | Adjustable flow control valve |
