John Deere H360
  • + Expand All
  • - Close All
  • Loader removal (parking) made easy
    Parking standsParking stands

    John Deere loaders are easily removed and reinstalled on tractors without tools. The parking system allows removing or attaching the loader to the tractor in minutes without the need for tools.


    To remove or park the loader, apply slight down pressure to the loader boom with the bucket dumped at approximately a 30-degree angle. With the tractor in park, install the parking stands and place the mast pins in the open position.


    To watch a video of parking and attaching an H-Series loader, click here.

    Removing or parking the loader
    Bucket slightly dumped and down pressureBucket slightly dumped and down pressure
    Parking stand in stored positionParking stand in stored position
    Removing parking standRemoving parking stand
    Bucket slightly dumped - Parking stands installedBucket slightly dumped - Parking stands installed
    Mast pin in the closed positionMast pin in the closed position
    Mast pin in the open positionMast pin in the open position

    Utilizing the boom circuit with the tractor in neutral, rotate the mast forward until the mast has rotated past the pin location on the mounting frame by extending the lift cylinder. Now using the bucket circuit, roll back the bucket until the mast is removed from the pocket and will clear the tires.

    Masts rotated forward, then bucket rolled backMasts rotated forward, then bucket rolled back

    With the tractor in park, shut the engine off and relieve the hydraulic pressure as indicated for the tractor. Relieve pressure on the single-point hydraulic connection, then disconnect or open the single-point hydraulic connector.

    Relieving the hydraulic pressureRelieving the hydraulic pressure
    Disconnect/open single point hydraulic connectionDisconnect/open single point hydraulic connection

    Store the loader half of the single-point connector. The tractor is now ready to back away from the loader.

    Storing the hydraulic hosesStoring the hydraulic hoses
    Tractor ready to be backed away from loaderTractor ready to be backed away from loader
    Backing away from loaderBacking away from loader
    Parked loaderParked loader
  • Single-point hydraulic connection saves time
    Single-point hydraulic connection (open)Single-point hydraulic connection (open)
    Single-point hydraulic connection (closed)Single-point hydraulic connection (closed)

    The H340 and H360 Loaders can be ordered with a single-point hydraulic connection that also incorporates the connection point for any electrical needs. To disconnect the hydraulic connection between the loader and the tractor, it is necessary to relieve the hydraulic system oil pressure on the tractor.

  • False rod bucket cylinders improve productivity mechanical self-leveling (MSL) only
    False rod cylinderFalse rod cylinder

    Fast bucket cycle times are important to dump the load from the bucket as quickly as possible (quite often) in order to be as productive as possible while completing loading operations. The bucket cylinder design can have a major impact on this cycle time, especially for the MSL loaders.


    Therefore, all MSL H-Series Loaders utilize false rod bucket cylinders. A false rod cylinder has a smaller displacement of oil requirement on the head end of the cylinder, which allows this cylinder to dump much faster than a normal cylinder.

  • Boom lockout for easy service
    Hydraulic shut-off valve (open position)Hydraulic shut-off valve (open position)
    Hydraulic shut-off valve (closed position)Hydraulic shut-off valve (closed position)

    A hydraulic shut-off valve is included with the H-Series Ag Loaders to ensure the loader does not lower suddenly. For example, this allows the boom to be locked out when someone is required to be located under the loader boom for service work on the tractor. It should not be used for extended periods of time unless an appropriate support stand is also utilized.

  • Concealed oil lines improve appearance and reduce damage
    Concealed oil lines through boom armConcealed oil lines through boom arm
    Oil lines routed through the boom armOil lines routed through the boom arm
    Oil lines routed through the torque tubeOil lines routed through the torque tube

    Over time, increased width in tractor hoods have caused issues with available space for running traditional oil lines of a loader along the boom, making them more susceptible to damage.


    To improve this situation, the oil lines have been routed through the boom arm and the torque tube, improving line protection and the appearance of the loader.


Leveling configuration Non-Self Leveling (NSL)
Bucket used Heavy Duty 2450 mm
Heavy Duty 96 in.
Bucket weight 358 kg
789 lb
Lift capacity at full height Measured at pivot (U)
1843 kg
4063 lbMeasured at 800 mm ahead of pivot (V)
1314 kg
2897 lb
Lift capacity at 59 in. (1500 mm) Measured at pivot (W)
2703 kg
5959 lbMeasured at 800 mm ahead of pivot (X)
2121 kg
4676 lb
Boom breakout force Measured at pivot (Y)
3592 kgf
7919 lbfMeasured at 800 mm ahead of pivot (Z)
2681 kgf
5911 lbf
Bucket rollback force capacity At ground-level line (ZZ)
3401 kgf
7498 lbf
Dimensions Maximum lift height (A)
4279 mm
168.5 in.At full height - bucket level(B)
4066 mm
160.1 in.At full height - bucket dumped (C)
3544 mm
129.5 in.
Digging depth (H) 125 mm
4.9 in.
Reach At maximum height (D)
699 mm
27.5 in.At ground level - bucket level (F)
2450 mm
96.5 in.
Bucket angle Dump angle, degrees (E)
-55 degree (angle)Rollback angle, degrees (G)
33 degree (angle)Dump angle, ground
-142 degree (angle)
Cycle times Loader raise, seconds
4.19 secondsLoader lower, seconds
2.87 secondsBucket dump, seconds
2.31 secondsBucket rollback, seconds
1.55 seconds
